AHP Series MD up to 350 bar

Mill Duty Type Cylinders

Mill duty cylinders are manufactured according to ISO 6022 Standardization up to 350 Bar pressure.

Cylinders are available in different mountings
• Front Circular Flange Mounting – MF3
• Rear Circular Flange Mounting – MP4
• Rear Clevis/ Pivot Mounted with Spherical bearing- MP6
• Side Lugs/ Foot Mounting – MS2
• Intermediate Trunnion Mounting – MT4

Cylinders designed for extreme conditions

Mill type cylinders are designed for applications even under extreme conditions
• Service-friendly modular system
• Various types of mounting
• Interchangeability, thanks to standardization
• Industry-specific and project-related cylinders on enquiry

Heavy Duty Mill Type Cylinder Series 1X/2X

Features :
• Nominal pressure : 250 bar
• Piston Ø : 40 to 320mm
• Piston rod Ø : 22 to 220mm
• Mounting types : 6
• Max. stroke length : 6000mm
• Max. stroke speed : 0.5m/s

ISO 6022 Mill Type Cylinder Series 1X

Features :
• Nominal pressure : 250 to 350 bar
• Piston Ø : 40 to 320mm
• Piston rod Ø : 25 to 220mm
• Mounting types : 6
• Max. stroke length : 6000mm
• Max. stroke speed : 0.5m/s

ISO 6022 - Front Circular Flange Mounting - Style MF3

Hydraulic Cylinder Specifications
Bore	ØBmm
Stroke	< 1000 ±1mm
Rod	Rod Ømm Hardchrome Plated 25μ thk
Mounting	Front Circular Flange MF3 Mounting
Working pressure	160 bar
Design	Mill Duty Double Acting
Max. speed	0.5m/sec.
Test pressure	210 bar
Medium	Hydraulic Mineral Oil

Ordering code
AHP - MD - MF2 - Bore x Rod x Stroke

ISO 6022 - Rear Circular Flange Mounting - Style MF4

Hydraulic Cylinder Specifications
Bore	ØBmm
Stroke	< 1000 ±1mm
Rod	Rod Ømm Hardchrome Plated 25μ thk
Mounting	Rear Circular Flange MF4 Mounting
Working pressure	160 bar
Design	Mill Duty Double Acting
Max. speed	0.5m/sec.
Test pressure	210 bar
Medium	Hydraulic Mineral Oil

Ordering code
AHP - MD - MF4 - Bore x Rod x Stroke

ISO 6022 - Rear Pivot Mounted Hydraulic Cylinders with Spherical Bearing - Style MP6

Hydraulic Cylinder Specifications
Bore	ØBmm
Stroke	< 1000 ±1mm
Rod	Rod Ømm Hardchrome Plated 25μ thk
Mounting	Rear Pivot Mounting MF6
Working pressure	160 bar
Design	Mill Duty Double Acting
Max. speed	0.5m/sec.
Test pressure	210 bar
Medium	Hydraulic Mineral Oil

Ordering code
AHP - MD - MP6 - Bore x Rod x Stroke

ISO 6022 - Rear Pivot Mounted Hydraulic Cylinders with Spherical Bearing - Style MP6

ISO 6022 - Side Lugs Mounting - Style MS2

Hydraulic Cylinder Specifications
Bore	ØBmm
Stroke	< 1000 ±1mm
Rod	Rod Ømm Hardchrome Plated 25μ thk
Mounting	Rear Pivot Mounting MF6
Working pressure	160 bar
Design	Mill Duty Double Acting
Max. speed	0.5m/sec.
Test pressure	210 bar
Medium	Hydraulic Mineral Oil

Ordering code
AHP - MD - MS2 - Bore x Rod x Stroke

ISO 6022 - Intermediate Trunnion Mounting - Style MT4

Hydraulic Cylinder Specifications
Bore	ØBmm
Stroke	< 1000 ±1mm
Rod	Rod Ømm Hardchrome Plated 25μ thk
Mounting	Intermediate Trunnion Mounting MT4
Working pressure	160 bar
Design	Mill Duty Double Acting
Max. speed	0.5m/sec.
Test pressure	210 bar
Medium	Hydraulic Mineral Oil

Ordering code
AHP - MD - MT4 - Bore x Rod x Stroke

ISO 6022 - Intermediate Trunnion Mounting - Style MT4
